Products Name:Model UK mechanical seal

Products Details:Mechanical seal type UK is a built-in type, single spring, type and drive pin transmission; using U ring ring rotary self locking ring seal, good performance, reliable sealing, stable performance, according to different working conditions need to choose different materials, different friction materials and structures. At the same time, cooling and flushing can be carried out according to the AP1610 standard.

Operating parameters:
The pressure in the seal cavity: 0~1.5MPa seal cavity temperature: -30 ~180 DEG C, the seal cavity speed: less than 3000r/min, sealed medium: water, sewage, oil and other weak corrosive liquid.
